5.2.2 SURFACE PREPARATION
Efacec recommends a concrete pad of at least 800mm (31.5”) square, by 254mm (10”) deep. Check local codes
to ensure compliance.
Flatness
To avoid warping of the doors, the Quick Charger Station power cabinet must be mounted on a surface with a
maximum slope of 2mm/m (¼ inch rise per 10 feet of run).
5.2.3 RESOURCES FOR INSTALLATION
The following resources will be needed for installation of the EFAPOWER EV-QC45:
Fasteners:
 4 (four) chemical anchors, M8 (5/16’’), 10mm thread diameter – length must comply with local codes, but
must have at least 120mm (5”)
 4 (four) galvanized bolts M8 (5/16’’), with matching nuts and washers (must extend at least 30.5mm (1.2”)
above the concrete and 89.5mm (3.52”) into the concrete)
 4 (four) sealing screws: Socket head button cap screws M12x25 (metric), with matching flat rubber washers
(supplied with the Quick Charging Station)
End terminals for input wiring:
 Depending on the EFAPOWER EV-QC45 configuration:
 Only DC outputs: 5 (five) end terminals up to 35mm
2
(3phases + neutral + protective ground), or
 DC and AC outputs (not available for US market): 5 (five) end terminals up to 35mm
2
+ 5 (five) end
terminals up to 16mm
2
(3phases + neutral+ protective ground)
Tools:
 13mm (1/2") wrench - for anchoring the Unit on the pad
 10mm Hex key/bit - for Sealing Screws
 Crimping tool - for power and earth cables
 Torque screwdriver with flat blade - for input terminal blocks
5.2.4 SITE VERIFICATION AND INSPECTION
 Check if Quick Charger has the appropriate upstream protection depending on the configuration of it
 Check if the surface where the Quick Charging Station will be placed is leveled as specified
