efacec EFAPOWER EV-QC45 - General Characteristics; Technical Characteristics; Standards

3/32
2 GENERAL CHARACTERISTICS
2.1 TECHNICAL CHARACTERISTICS
EFAPOWER EV-QC45 technical characteristics are indicated in the Table 1.
This unit is intended to have at least one DC output connection (CHAdeMO and/or CCS) and in addition can
have one of the two AC output
1
connections (AC43 or AC22).
Table 1 – EFAPOWER EV-QC45 Technical Characteristics
Specifications are subject to change, without prior notice.
In case of an AC output connection one of the following scenarios can be supplied:
 AC and DC output connections can only charge one at a time:
In this case only the nominal current input referred above in Table 1 is needed.
 AC and one DC output connections can charge simultaneous:
- For AC43: the total nominal current input needed is 136 A.
- For AC22: the total nominal current input needed is 105 A.
1
AC output not available for US market
Technical Data
CE
ETL
Nominal Input
Phases/Lines
3 phases + neutral + PE
Voltage
(400 ± 10%) V a.c.
(480 ± 10%) V a.c.
Current
73 A
64 A
Power
53kVA (@50kW peak power); 48kVA (@45kW)
Frequency
(50 ± 10%) Hz
(60 ± 10%) Hz
Efficiency
> 93%
Power Factor
0,98
THD Input Current
12,3
DC Output:
CHAdeMO
Voltage
(50 to 500) V d.c.
Current
120 A d.c.
Nominal Power
50kW at peak; 45kW at continuous
Communications with EV
JEVS G104 - CHAdeMO
Plug
JEVS G105 - CHAdeMO
DC Output:
CCS
Voltage
(50 to 500) V d.c.
Current
120 A d.c.
Nominal Power
50kW at peak; 45kW at continuous
Communications with EV
PLC
Plug
CCS – Type 2
SAE – Type 1
AC Output:
AC43 (or AC22)
Voltage
(400 ± 10%) V a.c.
Current
63 A a.c. (or 32 A a.c.)
Nominal Power
43kVA (or 22kVA)
Not Available
Plug (or Socket)
IEC62196 Type 2
Insulation
Input / Output / Ground
1500 V a.c.
1500 V a.c.
Control Circuit / Ground
500 Vac
Cabinet
Dimensions(WxDxH)
600 x 600 x 1800 mm
24” x 24” x 74.5” high
Weight
600 kg
1,323 lbs.
Protection Degree
IP54, IK10
IP54, IK10, NEMA 3R
HMI and Command
Unit
Contactless card specification
Mifare Classic 1K&4K | Mifare DesFire EV1
(Others under request)
Local interface
TFT Color display 6.4”
Buttons
Communication
Protocol (others under request)
Web Services over IP; Router 3G (GSM or CDMA)
OCPP; Efacec; others
Emergency STOP
Yes
Environment
Conditions
Temperature
Cold option (under request)
-25ᵒ to +50ᵒC
-35ᵒ to +50ᵒC
-13ᵒ to +122ᵒF
-31ᵒ to +122ᵒF
Humidity
5% to 95%
Place of installation
Indoor / Outdoor
Altitude
Up to 1000m
Up to 3280 feet
Sound Noise
<55 dB in all directions
