6 START-UP
6.1 VERIFICATION AND INSPECTION
Check if the bolts of the AC and protective ground cables of the Quick Charging Station are correctly
tightened to the specified torque
Check the resistance between the Quick Charger protective ground and the low voltage switchboard
ground connection; the value must be according to local codes
Before switching ON all the fuses and circuit breakers, check the supply voltage between lines: it must be
400V ± 10% 50Hz, for CE marked Units (and 480V ± 10% 60Hz for ETL marked Units)
At this stage, whenever the Unit shall be integrated with a Network Management System, Efacec shall
already have the following information:
For Unit configuration: Station(s) ID and Central Management Endpoint
For Router configuration: APN and PIN, Username and Password (if applicable)
6.2 SWITCH ON
BEFORE ATTEMPTING TO INSTALL OR START UP THE EFAPOWER EV QC45 QUICK
CHARGING STATION THE USER MUST ENSURE THAT THE SAFETY INSTRUCTIONS
IN THIS MANUAL ARE CAREFULLY READ AND OBSERVED BY TECHNICALLY
COMPETENT PERSONNEL.
KEEP THIS MANUAL WITH THE EFAPOWER EV QC45 QUICK CHARGING STATION
FOR FUTURE REFERENCE.
THIS EFAPOWER EV QC45 QUICK CHARGING STATION MUST NOT BE STARTED OR
PUT INTO USE WITHOUT HAVING BEEN COMMISSIONED BY A FULLY TRAINED
AND AUTHORIZED PERSON.
ALL SERVICING MUST BE PERFORMED ONLY BY QUALIFIED PERSONNEL. DO NOT
ATTEMPT TO SERVICE THE EFAPOWER EV QC45 QUICK CHARGING STATION
YOURSELF.
BY OPENING THE DOOR OR REMOVING THE EFAPOWER EV QC45 QUICK
CHARGING STATION SIDE PANELS YOU RUN THE RISK OF EXPOSURE TO
DANGEROUS VOLTAGES!
IN CASE OF ANY KIND OF DOUBT REGARDING THIS, PLEASE CONTACT:
EFACEC WILL ASSUME NEITHER RESPONSIBILITY NOR LIABILITY DUE TO
INCORRECT OPERATION OR MANIPULATION OF THE EFAPOWER EV QC45 QUICK
CHARGING STATION.
EFACEC HAS TAKEN EVERY PRECAUTION TO PRODUCE AN ACCURATE, COMPLETE
AND EASY TO UNDERSTAND MANUAL AND WILL THEREFORE ASSUME NO
RESPONSIBILITY NOR LIABILITY FOR DIRECT, INDIRECT OR ACCIDENTAL
PERSONAL OR MATERIAL DAMAGE DUE TO ANY MISINTERPRETATION OR
UNDESIRED MISTAKES IN THIS MANUAL.
THIS MANUAL MAY NOT BE COPIED NOR REPRODUCED WITHOUT PRIOR
WRITTEN PERMISSION OF EFACEC
