EFD 2000XL User Manual

STOP
Run
Setup
Fast Slow
Time Set
Pressure
Time
Time Set
Fast Slow
STEADYSTEADY
RUN
SETUP
CYCLE
Pressure
Vacuum
Steady
Teach
Cell Select
Vacuum
Pressure
®
A NORDSON COMPANY
2000XL
Note: Plant air, 125 psi maximum to regulator. Output from
regulator should be a minimum of 80 psi, maximum 100 psi.
For model 2000XL-PR5, output from regulator should be
set at 30 psi.
❸
Check voltage label
on dispenser.
Male
quick-connect,
insert and twist
to lock.
Barrel
adapter
assembly
Air input hose
Power cord
Foot pedal
assembly
❹
❺
Note: For hookup purposes,
the connections for the 2000XL,
2000XL-PR5 and 2000XL-CA
models are identical.
❻
❶
❷

EFD 2000XL Specifications

General

Brand	EFD
Model	2000XL
Category	Dispenser
Language	English
