EFKA DA320G5351
28
Supplier Level
Code no. 311 with control operation
Code no. 3112 with control panel operation
Parameter Designation Unit Limits Preset for Ind.
max min 100Ω 220Ω 680Ω 1000Ω
253 cA Number of stitches until enabling of output A 100 0 0 0 0 0 A
Function with parameter 250 = 5, 9
254 cA_ Number of stitches until disabling of output A 100 0 0 0 0 0 A
Function with parameter 250 = 9, 11
255 Fmb Function modules for output B on socket A/32 14 0 11 11 11 11 A
and input B on socket A/7 active only if
parameter 250 is not equal to 10.
0 = No function
1 = Switch stitch length
2 = Fullness control with speed limitation
3 = Fullness control without speed limitation
4 = Single stitch with stitch length switching
5 = Lift / lower roller
6 = Lift / lower fabric endstop
7 = Thread tension reduction
8 = Manual edge trimmer
9 = Automatic edge trimmer
10 = Triflex function: affects stitch length, thread
tension, speed limitation, automatic backtack
and function module for output A
(parameter 250 = 7)
11 = High lift for walking foot
12 = Function as with parameter 250
13 = Handwheel runs in the direction of rotation
according to setting of parameter 161
14 = Handwheel runs in the opposite direction of
rotation according to setting of parameter 161
256 bFA Output B (A/32) and LED B (A/31) after thread 1 0 0 0 0 0 A
trimming
0 = Output signals are maintained as before
thread trimming
1 = Output signals as after power On
Function with pa. 255 = 1, 2, 3, 7, 8, 9, 10
257 bin Output B (A/32) 1 0 0 0 0 0 A
0 = Output not inverted
1 = Output inverted
258 cb Number of stitches until enabling of output B 100 0 0 0 0 0 A
Function with parameter 255 = 5, 9
259 cb_ Number of stitches until disabling of output B 100 0 0 0 0 0 A
Function with parameter 255 = 9, 11
260 PLc Time interval which can be varied by means of the 1 0 0 0 0 0 A
number of stitches performed after sewing foot
lowering until roller lowering in the seam On/Off
(only if parameter 250 = 5 or 255 = 5).
At ouput A stitch setting with parameter 253
At output B stitch setting with parameter 258
0 = Time interval which can be varied by the
number of stitches performed OFF
1 = Time interval which can be varied by the
number of stitches performed ON
261 FLk 0 = Lift roller, but without sewing foot lift and 3 0 1 1 1 1 A
backtack
1 = Lift roller with sewing foot lift and backtack
2 = Lift roller with sewing foot lift
3 = Lift roller with backtack
Effective only if parameter 250 or 255 = 5
