EFKA DA320G5351
32
Supplier Level
Code no. 311 with control operation
Code no. 3112 with control panel operation
Parameter Designation Unit Limits Preset for Ind.
max min 100Ω 220Ω 680Ω 1000Ω
283 LSP Function “machine run blockage” 2 0 0 0 1 1 A
0 = Function Off
1 = Blockage 1, without positioning
2 = Blockage 2, with positioning
284 StP Start and end backtack can be interrupted with 1 0 0 0 0 0 A
pedal in position 0 (neutral) On/Off
287 dbA Speed limitation DB3000 (n11) for manual 1 0 0 0 0 0 A
backtack
0 = Speed limitation Off
1 = Speed limitation On
288 n9 Speed limitation (n9) for manual RPM 3000 200 1700 400 800 1200 A **)
ornamental backtack
289 n11 Speed limitation (n11) DB3000 RPM 6000 500 3000 500 1700 3000 A **)
291 810 Select slide-in strip number for the V810 control 8 0 1 1 1 1 A
panel
292 820 Select slide-in strip number for the V820 control 10 1 1 1 1 1 A
panel
293 tF1 Selection of the input function using the (A) 19 0 17 17 17 17 A
key “F1” on the V810/V820 control panel
0 = No function
1 = Needle up/down
2 = Needle up
3 = Single stitch (basting stitch)
4 = Full stitch
5 = Needle to position 2
6 = Output A, if parameter 250 > 0
7 = Output B, if parameter 255 > 0
8 = Operation in the direction of rotation
9 = Operation in the opposite direction of
rotation
10...12 = No function
13 = High lift for walking foot with speed
limitation n10 (operational mode not stored)
14 = High lift for walking foot with speed
limitation n10 (operational mode stored)
15 = No function
16 = Intermediate backtack
17 = Backtack suppression / recall
18 = No function
19 = Reset bobbin thread monitor
294 tF2 Selection of the input function using the (B) 19 0 1 1 1 1 A
key “F2” on the V810/V820 control panel
Functions of the key as with parameter 293
297 tFL Time monitoring of sewing foot lift sec 250 0 0 0 180 0 A
(monitoring off at “0“)
298 EF- Upper limit (pa. 204) ON period for % 100 1 100 100 100 100 A
sewing foot lift 1...100
299 EV- Upper limit (pa. 213) ON period for % 100 1 100 100 100 100 A
backtacking 1...100
**) When programming the 3-digit or 4-digit control parameter values (without control panel), the 2-digit or 3-digit
value displayed must be multiplied by 10.
