1
LIb-protocol
Select “ LIb” if using Lithium battery
compatible to Lib protocol. If
selected, programs of 11, 17, 18 and
19 will be automatically set up. No
need for further setting.
3
rd
party Lithium
battery
If selected, programs of 11, 17, 18
and 19 will be automatically set up.
Please contact the battery supplier
for installation procedure.
17
Bulk charging voltage
(C.V voltage)
Default setting: 56.4V
If self-defined is selected in program 14, this program can
be set up. Setting range is from 48.0V to 64.0V. Each click is
an increment of 0.1V.
18 Float charge voltage
Default setting: 54.0V
If self-defined is selected in program 14, this program can
be set up. Setting range is from 48.0V to 64.0V. Each click is
an increment of 0.1V.
19
Low DC cut off battery voltage
setting
Default setting: 40.8V
If self-defined is selected in program 14, this program can be
set up. Setting range is from 40.8V to 48.0V. Each click is an
increment of 0.1V. Low DC cut-off voltage will be fixed to
setting value no matter what percentage of load is
connected.
20
Bypass loads to grid when
grid is present.
default setting: 46V
Setting range is from 44V to 51V
and each click is an increment of
1V.
In EG4 Mode you will see a
percentage instead
21
Set point for transfer back to
off-grid operation if system is
bypassed based on 20
Battery fully charged
The setting range is from 48V to
58V, Each click is an increment of
1V.
In EG4 Mode you will see a
percentage instead
Default setting: 54V
