10.2 RS485 PROTOCOL AUTODETECTION
NOTE:
When using RS485 communications, the battery will auto detect the inverter protocol being
CODE DIP SWITCH POSITION BRAND COMMUNICATIONS
64
EG4 RS485
64
Growatt RS485
64
Schneider RS485
Confirm that the RS485 cable being used is pinned correctly in respect to the inverter being used.
PIN DESCRIPTION
BMS ON/OFF switch will have to be powered off and back on for the address
changes to take effect and reengage.
