7.2 LED INDICATOR STATUS & DEFINITION
STATUS
NORMAL/
ALARM/
PROTECTION
RUN ALM
SOC INDICATOR
LED
NOTES
SOC1~SOC4 -
Shutdown/Sleep
OFF
OFF
OFF
-
Stand-by
Normal ON OFF
Based on battery
indicator
(Each LED indicates
25% SOC)
-
Alarm ON FLASH
According to
the state
before
stand-by
Charge
Normal Short flash OFF -
Alarm Short flash Short flash -
End-off Voltage OFF ON -
Over-temp
Protection
OFF Short flash -
Over-current
transfer limit
protection
Short flash
Short
flash/OFF
-
Discharge
Normal Long flash OFF
Based on battery
indicator
-
Alarm Long flash Long flash -
End-off voltage OFF OFF Go to sleep
Over-temp/
Over-current
protection
OFF ON -
BMS Fault - OFF Flash All OFF -
