EG4 LiFePower4 - 10 Protocol Select; Protocol ID Dip Switch

16
10. PROTOCOL SELECT
10.1 PROTOCOL ID DIP SWITCH
NOTE:
The Complete Link Protocol and the Simplified Link Protocol will ONLY work with
CAN communication, not RS485.
CODE DIP SWITCH POSITION BRAND COMMUNICATIONS
1 EG4/Lux CAN
2 Growatt CAN
3 Sol-Ark CAN
4 Deye CAN
5 Megarevo CAN
6 Victron CAN
7 Luxpower CAN
8 SMA CAN
Note: Protocol DIP switch 6 will be used to allow battery communication to the other batteries
depending on which battery version you have.
9 Complete LINK protocol
In the “ON” position, this allows
the battery to communicate with
the Indoor and Outdoor
WallMount and version 2 LL’s
and original batteries with the
Multipack firmware.
10 Simplified LINK protocol
In the “OFF” position, this allows
the battery to communicate with
version 1 LL’s and original
LifePower4 with the Multipack
firmware.
