product operating instruction
E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH)
document id.: 90.60160.286-001-04-A / state: 230 - released
designation: Induction Gx
Preconditions
Necessary Tools:
Power screwdriver with adjustable tightening torque and Torx TX15, 20 and 25 bits
Necessary screws:
Description of screw Type numbers of references Drawings of references
Screw for strain relief (side
entrances Gx generator) and
strain relief for connection box
969.173 90.03302.350-001
Screw for connection of Gx
generator and mounting plate
98.302.04 C000018293-002
Screw for earthing terminal 967.279 967.279-002
Tab. 4: Necessary screws for Gx assembly
The following distances are recommended between different objects:
Description of
objects
Recommended
distances
Comments
Octa inductor –
Octa inductor
Minimum and
recommended in
bridge mode: 10
mm
Maximum: 35 mm
The distances are based on the outer edge of the first
inductor’s mica sheet to the outer edge of the further
inductor’s mica sheet.
In bridge mode it must be secured that NTC sensors of
both coils are covered by the cookware. A four-way
bridging of Octa inductors (horizontally and vertically) is
not allowed.
It is recommended to check the minimum distance that
two kinds of cookware can be used on bridgeable
cooking zones within a deactivated bridge function.
A reduction of the minimum distance between inductors
may cause louder noises. Furthermore, the lower pot
detection limit may increase especially when two cookware
on the concerned coils are operated at different power
levels. Positioning coils too close to each other can cause
cookware to be detected, which are not placed on this
position. Therefore, a reduction under the recommended
minimum distances must be avoided. By increasing the
distances, the heat distribution in the cookware is
decreasing. Larger coils distances and the same cookware
size (compared to same coils, which are closer together)
lead to less coverage on each inductor. This results in either
significantly reduced power in the cookware or higher stress
on the inductor. Furthermore, it must be ensured in the
system that at least one of the NTC sensors is always
covered by the cookware.
Round inductor –
Round inductor
Minimum: 10 mm
Minimum in bridge
mode: 10 mm
Maximum: 35 mm
(related to two 180
mm inductors)
To Next Page
