EHRLE Series - 3.6 Device Views KD940 Premium

300781 • 1/2019 • H.S.
19 of 70
Operating Instruction
High Pressure Cleaner cold water, mobile
Series 3x3
3 Product information
3.6 Device views KD940-Premium
9
1
2
3
4
5
10
7
8
6
11
12
1 Trigger gun 6 High pressure outlet (pump)
2 Hose reel 7 Unloader valve
3 Control panel with 8 Spray lance with rotary nozzle
Detergent control valve (blue) and 9 Spray lance with nozzle protection
Device switch 0/I (red) 10 Mains cable connection 3x400 VAC
4 Water supply separation tank 11 Detergent suction hose with filter
5 Pressure gauge 12 Connection water inlet with adapter
Fig. 3 - 6 KD940-Premium, total and rear view
