EHRLE Series - Operation; 6.1 Device Controls and Indicators

300781 • 1/2019 • H.S.
45 of 70
Operating Instruction
High Pressure Cleaner cold water, mobile
Series 3x3
6 Operation
6 Operation
6.1 Control and indicator elements of device
Device version Standard Device version Premium
1
2
3
1
2
3
4
Food appliance Standard Food appliance Premium
1
2
3
1
2
3
4
1 Unloader valve 3 Device switch 0/I
2 Pressure gauge 4 Detergent control valve (only Premium)
Fig. 6 - 1 Controls and indicator elements, examples for version Standard and Premium
