Operating Instruction
High Pressure Cleaner cold water, mobile
Series 3x3
3 Product information
3.7 Device views KD940-F-Standard
(food appliance)
1
2
3
4
5
9
7
8
6
10
1 Trigger gun 6 High pressure outlet (pump)
2 Device switch 0/I 7 Unloader valve
3 Detergent container 8 Double spray lance 900 mm
4 Pressure gauge with nozzle protection
5 Connection water inlet 9 Filler neck for cleaning detergent
with adapter 10 Mains cable connection 3x400 VAC
Fig. 3 - 7 KD940-F-Standard food appliance, total and rear view
