300781 • 1/2019 • H.S.
46 of 70
Operating Instruction
High Pressure Cleaner cold water, mobile
Series 3x3
6 Operation
6.2 Control elements of the trigger gun
The following figure shows the control elements of the trigger gun.
To assemble (disassemble) the spray lance to the (from the) trigger gun see
arrows in the figure below.
4
5
3
6
2
1 2
1 Trigger gun
2 Quick lock
3 Spray lance
4 Trigger lever
5 Locking lever (safety device)
6 Notch for locking lever (safety arresting)
Fig. 6 - 2 Control elements of trigger gun
