Eighteeth HyperLight-G - X-Ray Tube Specifications and Characteristics

10 Technical Data
Page 33 / 42
10.2 X-ray Tube Specifications and Characteristics
Filament voltage
3.2-3.9V
Maximum filament current
2.8A
Nominal tube voltage
70kV
X-ray source assembly
maximum heat content
7000J
Maximum anode cooling rate
130W
Nominal anode input power
1000W
Target material
Tungsten
Minimum target angle
16°
Filament voltage (at maximum
filament current 2.9A)
3.2-3.9V
Minimum permanent filtration
(IEC 60522:1999)
0.8mm/75kV
Nominal focal spot (IEC
60336:1993)
0.7mm
Emission&Filament Characteristics:
