Electronic specifications:
Transmission rate: 9600 bps or higher
Byte type: hexadecimal
Length of each byte: 8 bits
Parity: none Flow control: none Stop bit: 1
Line information content: 10-19 designations ( see # in table ).
Line Length in bytes varies and depends on which object in the range of possibilities is actually
activated.
TABLE 1.0 Ron TRANSMISSION RS-232 PROTOCOL - Indicator to PC/Printer
Tx direction
#
Designation
Function
Possibilities
Range
Length
In Bytes
1
LOAD
Value of measurement
Data
1-7
2
tab
space
tab
1
3
UNITS
Measurement units
KG
S.TON
DECA .N
K.NTON
LBS
LB.*10
S. TON
M. TON
2
5
6
6
3
6
5
5
4
tab
space
tab
1
5
TARE
Exclusion of fixed weight
Net
Gross
3
5
6
tab
space
tab
1
7
FUNCT
Current indicator command: data
Maximum measured this session
Data Logger
Totalizer
Set point1,Set point 2
Data
Max
D.L .xxx
Tot .NN
S.P1./ S.P2
4
3
5-8
6
10
8
tab
space
tab
1
9*
YY
Year
Year
2
10*
Space
Space
Space
1
11*
MM
Month
Month
2
12*
Space
Space
Space
1
13*
DD
Day
Day
2
14*
Space
Space
Space
1
15*
HH
Hour
Hour
2
16*
Space
Space
Space
1
17*
MN
Minute
Minute
2
18
0x0d
Carriage return (next line(
0x0d
1
19
0x0a
Start new line
0x0a
1
* APPLICABLE ONLY WHEN REAL TIME CLOCK (RTC) OPTION IS INSTALLED.
