Chapter 6
Reference
Attaching the original stand
1.
Detachthexingscrewsontheoptionalarm(oroptionalstand)andremovetheoptionalarm(oroptionalstand).
2.
Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down.
3.
Attach the original stand.
As shown below, insert the four tabs on the stand to the square holes on the back panel (1) and slide the stand towards the upper portion of the monitor
until it makes a clicking sound (2).
(1)
(2)
(2)
Click!Click!
