5-4. Preset Timing

The following table shows the factory preset video timing of the PC.

ATTENTION

Display position may be deviated depending on the PC connected, which may require screen adjustment using

Setting menu.

If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen

display may still be incorrect even after the adjustment.

When interlace signals are used, the screen cannot be displayed correctly even after screen adjustment using the

Setting menu.

•

FDX1001T/FDX1201T

Resolution

Applicable

signal

Frequency Polarity

Dot clock :

MHz

Horizontal :

kHz

Vertical :

Horizontal Vertical

720 × 400 VGA TEXT 28.33 31.47 70.09 Negative Positive

640 × 480 VGA 25.18 31.47 59.94 Negative Negative

640 × 480 VESA 31.50 37.86 72.81 Negative Negative

640 × 480 VESA 31.50 37.50 75.00 Negative Negative

800 × 600 VESA 36.00 35.16 56.25 Positive Positive

800 × 600 VESA 40.00 37.88 60.32 Positive Positive

800 × 600 VESA 50.00 48.08 72.19 Positive Positive

800 × 600 VESA 49.50 46.88 75.00 Positive Positive

1024 × 768 VESA 65.00 48.36 60.00 Negative Negative

640 × 480 MAC 30.24 35.00 66.67 Negative Negative

832 × 624 MAC 57.28 49.72 74.55 Negative Negative

640 × 400 PC-9801 21.05 24.83 56.42 Negative Negative

640 × 400 PC-9821 AP2 25.18 31.48 70.10 Negative Negative

FDV1001T
