Chapter 5 Reference
5-2. Specications
FDX1001T
LCD Panel Size 10.4-inch (260 mm) TFT color LCD
Surface treatment Anti-glare
Surface hardness 2H
Viewing angle Horizontal 160°, Vertical 130° (CR : 10 or more)
Dot Pitch 0.2055 mm
Display Area (H × V) 210.4 mm × 157.8 mm
Resolution 1024 dots × 768 lines
Max. Display Color Approx. 16.7 million colors
PC input Horizontal Scan Frequency 24-50 kHz
Vertical Scan Frequency 55-75 Hz (Non-interlace)
Max. Dot Clock 65 MHz
Input Signal Connector D-Sub mini 15-pin × 1
Input Signal (Sync) Separate, TTL, positive
/ negative
Input Signal (Video) Analog, Positive (0.7Vp-p/75Ω)
Max. Video Signal Memory 15 (preset : 13)
Plug and Play VESA DDC 2B/EDID structure 1.3
Touch Panel OS: Microsoft Windows 2000 Service Pack 4
Microsoft Windows XP Service Pack 3 (32 bit)
Microsoft Windows Vista Service Pack 1 (32 bit)
(Not compatible with Mac OS)
Communication protocol : RS-232C serial
Detective method : Analog resistive technology
Video input Applicable Format NTSC, PAL, SECAM
Input Signal Connector S-Video DIN mini 4 pin/ Video Pin jack × 1
Input Signal Level S-Video DIN mini 4 pin : Y 1.0Vp-p/75Ω, C 0.28Vp-p/75Ω
Video Pin jack : 1.0Vp-p/75Ω
Power Supply AC adapter (AC) : 100-240VAC±10%, 50/60Hz, 0.3-0.2 A (Max.)
Main unit (DC) : 12VDC±10%, 0.9 A
Power
Consumption
Screen Display On AC adapter (AC) : 14 W or less
Main unit (DC) : 11 W or less
Power Off AC adapter (AC) : 1.3 W or less
Main unit (DC) : 0.5 W or less
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit 252 mm
(9.9 inch) × 255 mm (10 inch) × 175 mm (6.9 inch)
Main unit (without stand) 252 mm (9.9 inch) × 216 mm (8.5 inch) × 45 mm (1.77 inch)
Mass Main unit Approx. 3.9 kg (8.6 lbs.)
Main unit (without stand) Approx. 2.3 kg (5.1 lbs.)
Movable
range
Tilt 30°Up, 0°Down
Swivel 35°Right, 35°Left
