23
Chapter 5 Reference
Environmental
Conditions
Temperature [Operating temperature]
Main unit : 0 °C - 50 °C (32 °F - 122 °F)
AC adapter : 0 °C - 40 °C (32 °F - 104 °F)
[Storage temperature]
-20 °C - 60 °C (-4 °F - 140 °F)
Humidity [Operating humidity]
Main unit : 20% - 90% R.H. (wet bulb temperature ≤ 39 °C (102
°F), no condensation)
AC adapter : 20% - 85% R.H.(no condensation)
[Storage humidity]
10% - 90% R.H. (wet bulb temperature ≤ 39 °C (102 °F), no
condensation)
Pressure [Operating] 700 hPa - 1060 hPa
[Storage] 200 hPa - 1060 hPa
FDV1001T
LCD Panel Size 10.4-inch (260 mm) TFT color LCD
Surface treatment Anti-glare
Surface hardness 2H
Viewing angle Horizontal 160°, Vertical 140° (CR : 10 or more)
Dot Pitch
0.33 mm
Display Area (H × V)
211.2 mm × 158.4 mm
Resolution
640 dots × 480 lines
Max. Display Color Approx. 16.2 million colors
PC input Horizontal Scan Frequency 24-32 kHz
Vertical Scan Frequency 56-70.5 Hz (Non-interlace)
Max. Dot Clock 31 MHz
Input Signal Connector D-Sub mini 15-pin × 1
Input Signal (Sync) Separate, TTL, positive
/ negative
Input Signal (Video) Analog, Positive (0.7Vp-p/75Ω)
Max. Video Signal Memory 10 (preset : 8)
Plug and Play VESA DDC 2B/EDID structure 1.3
Touch Panel OS: Microsoft Windows 2000 Service Pack 4
Microsoft Windows XP Service Pack 3 (32 bit)
Microsoft Windows Vista Service Pack 1 (32 bit)
(Not compatible with Mac OS)
Communication protocol : RS-232C serial
Detective method : Analog resistive technology
Video input Applicable Format NTSC, PAL, SECAM
Input Signal Connector S-Video DIN mini 4 pin/ Video Pin jack × 1
Input Signal Level S-Video DIN mini 4 pin : Y 1.0Vp-p/75Ω, C 0.28Vp-p/75Ω
Video Pin jack : 1.0Vp-p/75Ω
Power Supply
AC adapter (AC) : 100-240VAC±10%, 50/60Hz, 0.2-0.15 A (Max.)
Main unit (DC) : 12VDC±10%, 0.7 A
Power
Consumption
Screen Display On AC adapter (AC) : 10 W or less
Main unit (DC) : 9 W or less
Power Off AC adapter (AC) : 1.3 W or less
Main unit (DC) : 0.5 W or less
To Next Page
