24
Chapter 5 Reference
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit 252 mm
(9.9 inch) × 255 mm (10 inch) × 175 mm (6.9 inch)
Main unit (without stand) 252 mm (9.9 inch) × 216 mm (8.5 inch) × 45 mm (1.77 inch)
Mass Main unit Approx. 3.7 kg (8.2 lbs.)
Main unit (without stand) Approx. 2.1 kg (4.6 lbs.)
Movable
range
Tilt 30°Up, 0°Down
Swivel 35°Right, 35°Left
Environmental
Conditions
Temperature [Operating temperature]
Main unit : 0 °C - 50 °C (32 °F - 122 °F)
AC adapter : 0 °C - 40 °C (32 °F - 104 °F)
[Storage temperature]
-20 °C - 60 °C (-4 °F - 140 °F)
Humidity [Operating humidity]
Main unit : 20% - 90% R.H. (wet bulb temperature ≤ 39 °C (102
°F), no condensation)
AC adapter : 20% - 85% R.H.(no condensation)
[Storage humidity]
10% - 90% R.H. (wet bulb temperature ≤ 39 °C (102 °F), no
condensation)
Pressure [Operating] 700 hPa - 1060 hPa
[Storage] 200 hPa - 1060 hPa
FDX1201T
LCD Panel Size 12.1-inch (310 mm) TFT color LCD
Surface treatment Anti-glare
Surface hardness 2H
Viewing angle Horizontal 160°, Vertical 140° (CR : 10 or more)
Dot Pitch 0.240 mm
Display Area (H × V) 245.76 mm × 184.32 mm
Resolution 1024 dots × 768 lines
Max. Display Color Approx. 16.7 million colors
PC input Horizontal Scan Frequency 24-50 kHz
Vertical Scan Frequency 55-75 Hz (Non-interlace)
Max. Dot Clock 65 MHz
Input Signal Connector D-Sub mini 15-pin × 1
Input Signal (Sync) Separate, TTL, positive
/ negative
Input Signal (Video) Analog, Positive (0.7Vp-p/75Ω)
Max. Video Signal Memory 15 (preset : 13)
Plug and Play VESA DDC 2B/EDID structure 1.3
Touch Panel OS: Microsoft Windows 2000 Service Pack 4
Microsoft Windows XP Service Pack 3 (32 bit)
Microsoft Windows Vista Service Pack 1 (32 bit)
(Not compatible with Mac OS)
Communication protocol : RS-232C serial
Detective method : Analog resistive technology
