25
Chapter 5 Reference
Video input Applicable Format NTSC, PAL, SECAM
Input Signal Connector S-Video DIN mini 4 pin/ Video Pin jack × 1
Input Signal Level S-Video DIN mini 4 pin : Y 1.0Vp-p/75Ω, C 0.28Vp-p/75Ω
Video Pin jack : 1.0Vp-p/75Ω
Power Supply
AC adapter (AC) : 100-240VAC±10%, 50/60Hz, 0.4-0.25A
(Max.)
Main unit (DC) : 12VDC±10%, 1.4 A
Power
Consumption
Screen Display On AC adapter (AC) : 20 W or less
Main unit (DC) : 17 W or less
Power Off AC adapter (AC) : 1.6 W or less
Main unit (DC) : 0.8 W or less
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit 293 mm
(11.5 inch) × 271 mm (10.6 inch) × 175 mm (6.9 inch)
Main unit (without stand) 293 mm (11.5 inch) × 244 mm (9.6 inch) × 46 mm (1.8 inch)
Mass Main unit Approx. 4.4 kg (9.6 lbs.)
Main unit (without stand) Approx. 2.8 kg (6.1 lbs.)
Movable
range
Tilt 30°Up, 0°Down
Swivel 35°Right, 35°Left
Environmental
Conditions
Temperature [Operating temperature]
Main unit : 0 °C - 50 °C (32 °F - 122 °F)
AC adapter : 0 °C - 40 °C (32 °F - 104 °F)
[Storage temperature]
-20 °C - 60 °C (-4 °F - 140 °F)
Humidity [Operating humidity]
Main unit : 20% - 90% R.H. (wet bulb temperature ≤ 39 °C (102
°F), no condensation)
AC adapter : 20% - 85% R.H.(no condensation)
[Storage humidity]
10% - 90% R.H. (wet bulb temperature ≤ 39 °C (102 °F), no
condensation)
Pressure [Operating] 700 hPa - 1060 hPa
[Storage] 200 hPa - 1060 hPa
Main default settings (factory settings)
PC Video
Brightness 30
Contrast FDX1001T/FDX1201T: 30
FDV1001T: 24
15
Black Level 30 15
Sharpness Off
Saturation - 0
Hue - 0
Color Mode 1 -
Video Aspect Normal
Power Save Enable
Reverse Off
Crosshair Off
Beep On
Language English
Touch Panel PC+VIDEO
To Next Page
