Eizo FlexScan EV3895 User Manual

Audio Audio Input Format DisplayPort: 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz /
176.4 kHz / 192 kHz)
HDMI: 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz /
176.4 kHz / 192 kHz)
USB-C (DisplayPort Alt Mode): 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz /
176.4 kHz / 192 kHz)
Speakers 1 W + 1 W
Headphones 2 mW + 2 mW (32 Ω)
Input Terminals DisplayPort × 1, HDMI × 2, USB-C (DisplayPort Alt Mode) × 1 (each shared
with video signal)
Output Terminals Headphone jack × 1
Network Port RJ-45 (USB LAN Adapter)
Supported OS Microsoft Windows 10 (32-bit/64-bit)
Microsoft Windows 8.1 (32-bit/64-bit)
macOS Sierra (10.12) or later
Wired LAN IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX),
IEEE802.3 (10BASE-T)
Power Input 100 - 240 VAC ±10 %, 50 / 60 Hz 1.95 A - 0.85 A
Maximum Power
Consumption
194 W or less
Power Save Mode 0.5 W or less (no USB device connected, “USB” in the “Administrator
Settings” menu: O󰀨)
Standby Mode 0.5 W or less (no USB device connected, default settings)
Physical
Specications
Dimensions 893.9 mm × 418.2 mm to 633.2 mm × 281.4 mm to 307.6 mm (W × H × D)
(Tilt: 35˚)
893.9 mm × 411.0 mm to 603.7 mm × 240.0 mm (W × H × D) (Tilt: 0˚)
Dimensions
(Without Stand)
893.9 mm × 398.2 mm × 109.8 mm (W × H × D)
Net Weight Approx. 13.2 kg
Net Weight
(Without Stand)
Approx. 9.5 kg
Height Adjustment
Range
215.0 mm (Tilt: 35˚) / 192.7 mm (Tilt: 0˚)
Tilt Up 35.0˚, Down 5.0˚
Swivel 70.0˚
Operating
Environmental
Requirements
Temperature 5 ˚C to 35 ˚C
Humidity 20 % to 80 % R.H. (no condensation)
Air Pressure 540 hPa to 1060 hPa
Transportation /
Storage
Environmental
Requirements
Temperature -20 ˚C to 60 ˚C
Humidity 10 % to 90 % R.H. (no condensation)
Air Pressure 200 hPa to 1060 hPa
●
Accessories
For the latest information about accessories, refer to our web site www.eizoglobal.com.
47
Chapter 8 Reference

Eizo FlexScan EV3895 Specifications

General

Energy efficiency scale	A to G
