4-3. Linking the Input Signal and USB Port
When two or three PCs are connected to one monitor, you can link the input signal with the USB
upstream port. This makes it possible to connect USB devices such as a mouse or keyboard to the
monitor and use them from multiple PCs.
●
Connection Example
USB-A
Downstream
CC200SS-5A or
CC200SSW-5A
USB cable
(USB-C - USB-C)
(Included)
USB-C
Upstream
USB-C
LAN cable
(Commercially
available product)
PP200
DisplayPort cable
(DisplayPort -
DisplayPort)
(Included)
USB-A
DisplayPort
DisplayPort
LAN port
LAN port
USB-B
Upstream
UU200SS
USB 3.0 cable
(USB-B - USB-A)
(Included)
1.
Linking
Refer to “USB Selection” (page 24) to link the USB upstream port to the input signal.
31
Chapter 4 Connecting Multiple PCs
