Chapter 5 Reference
5-3 Specifi cations
LCD Panel 21.3-inch (540 mm) TFT color LCD with anti-glare hard coating
Viewing angle: Vertical 178°, Horizontal 178° (CR: 10 or more)
Dot Pitch 0.270 mm
Horizontal Scan Frequency Analog: 24 - 80 kHz (Automatic)
Digital: 31 - 76 kHz
Vertical Scan Frequency Analog: 49 - 76 Hz (Automatic)
(1600 × 1200: 49 - 61 Hz)
Digital: 59 - 61 Hz
(VGA TEXT: 69 - 71 Hz)
Resolution 1600 dots × 1200 lines
Max. Dot Clock Analog: 162 MHz
Digital: 162 MHz
Max. Display Colors 16.77 million colors
Display Area (H × V) 432 mm × 324 mm
Power Supply 100 - 120 VAC ±10% 50/60 Hz, 0.7 A
200 - 240 VAC ±10% 50 Hz, 0.4 A
Power Consumption Max.:70 W (USB device connected)
Power saving mode: 2 W or less (for single signal input with no USB device
connected)
Power switch Off: 1 W or less
Input Signal Connectors DVI-I connector, D-sub mini 15-pin connector
Analog Input Signal (Sync) a) Separate, TTL, positive/negative
b) Composite, TTL, positive/negative
Analog Input Signal (Video) Analog, positive (0.7 Vp-p/75 Ω)
Digital Signal Transmission
System
TMDS (Single Link)
Video Signal Memory Analog signal: 45 (preset: 22)
Digital Signal: 10 (preset: 0)
Plug & Play VESA DDC 2B
Dimensions (Main unit) 465 mm (W) × 453 - 535 mm (H) × 208.5 mm (D) (18.3” (W) × 17.8”-21.1” (H) × 8.2” (D))
Dimensions (without stand) 465 mm (W) × 361 mm (H) × 64 mm (D) (18.3” (W) × 14.2” (H) × 2.52” (D))
Weight (Main unit) 9.7 kg (21.4 lbs)
Weight (without stand) 6.7 kg (14.8 lbs)
Environmental Conditions Operating temperature: 0 °C - 35 °C
Storage temperature: –20 °C - 60 °C
Relative humidity: 30% - 80% (no condensation)
USB
Standard Rev. 2.0 compliant
Port Upstream port × 1, Downstream port × 2
Transmission rate 480 Mbps (High speed)
12 Mbps (Full speed)
1.5 Mbps (Low speed)
Supply current Downstream: Max. 500 mA/1 port
