Eizo FlexScan S2133 User Manual

41
Chapter6Reference
●
Accessories
Signalcable PP2000
CleaningKit EIZO“ScreenCleaner”
For the latest information about the accessories, refer to our web site.
http://www.eizo.com
6-6. Preset Timing
The following table shows factory preset analog signal timing.
Attention
• Display position may be deviated depending on the PC connected, which may require screen adjustment using Setting menu.
• If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may
still be incorrect even after the adjustment.
• When interlace signals are used, the screen cannot be displayed correctly even after screen adjustment using the Setting
menu.
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640×400 PC-9801 21.05 24.83 56.42 Negative Negative
640×400 PC-9821AP2 25.18 31.48 70.10 Negative Negative
640×480 VGA 25.18 31.47 59.94 Negative Negative
640×480 VESA 31.50 37.86 72.81 Negative Negative
640×480 VESA 31.50 37.50 75.00 Negative Negative
640×480 MAC 30.24 35.00 66.67 Negative Negative
720×400 VGATEXT 28.32 31.47 70.09 Negative Positive
800×600 VESA 36.00 35.16 56.25 Positive Positive
800×600 VESA 40.00 37.88 60.32 Positive Positive
800×600 VESA 50.00 48.08 72.19 Positive Positive
800×600 VESA 49.50 46.88 75.00 Positive Positive
832×624 MAC 57.28 49.72 74.55 Negative Negative
1024×768 VESA 65.00 48.36 60.00 Negative Negative
1024×768 VESA 75.00 56.48 70.07 Negative Negative
1024×768 VESA 78.75 60.02 75.03 Positive Positive
1152×864 VESA 108.00 67.50 75.00 Positive Positive
1152×870 MAC 100.00 68.68 75.06 Negative Negative
1280×960 VESA 108.00 60.00 60.00 Positive Positive
1280×960 MAC 126.20 74.76 74.76 Positive Positive
1280×1024 VESA 108.00 63.98 60.02 Positive Positive
1280×1024 VESA 135.00 79.98 75.03 Positive Positive
1600×1200 VESA 162.00 75.00 60.00 Positive Positive

Eizo FlexScan S2133 Specifications

General

3D	Yes
HD type	UXGA
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	4:3
Screen shape	Flat
Response time	20 ms
Display diagonal	21.3 \
Display resolution	1600 x 1200 pixels
Display technology	LED
Contrast ratio (typical)	1500:1
Display number of colors	16.78 million colors
Viewable size, horizontal	540 mm
Digital vertical frequency	49 - 76 Hz
Digital horizontal frequency	24 - 80 kHz
Display brightness (typical)	420 cd/m²
Supported graphics resolutions	720 x 400, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Quantity	1
HDMI ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
Pivot angle	0 - 90 °
Tilt angle range	- °
Number of OSD languages	6
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, SWE
Thin client installed	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	45 W
Power consumption (off)	0.1 W
Power consumption (standby)	0.3 W
Power consumption (typical)	17.4 W
Certification	CE, TÜV GS, TÜV, ISO 9241-307, TCO 6.0
Product color	Black
Cables included	DVI, USB
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	209 mm
Height (with stand)	535 mm
Weight (with stand)	8600 g
Depth (without stand)	64 mm
Width (without stand)	465 mm
Height (without stand)	361 mm
Weight (without stand)	5600 g
