Eizo FlexScan S2133

5
CONTENTS
CONTENTS
Cover ...................................................................... 1
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 7
1-1. Features ......................................................... 7
1-2. Controls and Functions ............................... 8
●
Front................................................................ 8
●
Rear................................................................. 9
1-3. EIZO LCD Utility Disk.................................... 9
●
Diskcontentsandsoftwareoverview............. 9
●
Touse“ScreenManagerProforLCD
(DDC/CI)/EIZOScreenSlicer”....................... 9
1-4. Basic Operations and Functions ...............10
●
BasicoperationoftheSettingmenu..............10
●
Functions........................................................11
Chapter 2 Adjusting Screens .......................... 12
2-1. Compatible Resolutions .............................12
●
AnalogInput(D-Sub).....................................12
●
DigitalInput(DVI-D).......................................12
●
DigitalInput(DisplayPort)..............................12
2-2. Setting the Resolution ................................13
●
Windows8/Windows7.................................13
●
WindowsVista................................................13
●
WindowsXP...................................................13
●
MacOSX.......................................................13
2-3. Adjusting Color ............................................14
●
Toselectthedisplaymode
(FineContrastMode)......................................14
●
Toperformadvancedadjustments................15
●
Adjustablesettingsineachmode..................15
●
Toadjustbrightness.......................................15
●
Toadjustcontrast...........................................16
●
Toadjustcolortemperature...........................16
●
Toadjustgamma...........................................17
●
Toadjustthecolorsaturation.........................17
●
Toadjusthue..................................................18
●
Tosetoverdriveintensity................................18
●
Toadjustgain.................................................19
2-4. Screen Adjustment ..................................... 20
●
DigitalSignalInput........................................ 20
●
AnalogSignalInput....................................... 20
2-5. Screen Size Changing ................................ 24
●
ScreenSizeChanging...................................24
●
Toadjustbrightnessofnon-displayarea.......24
Chapter 3 Setting Monitor ............................... 25
3-1. Enabling / Disabling DDC/CI
communication .......................................... 25
3-2. Locking Operation Buttons ....................... 25
3-3. Setting Orientation ..................................... 26
3-4. Showing and hiding the EIZO logo ........... 26
3-5. Changing Setting Menu Display Position 26
3-6. Setting Language ........................................ 27
3-7. Resetting the Monitor to the Default
Settings ........................................................ 27
●
Toresetthecoloradjustments...................... 27
●
Toresetalladjustmentstothedefault
settings.......................................................... 27
Chapter 4 Power Saving Functions ................ 28
4-1. Setting Power Saving ................................. 28
4-2. Setting Power Indicator .............................. 29
4-3. Enabling / Disabling Automatic
Brightness Adjustment ............................. 29
●
AutoEcoView................................................ 29
●
EcoViewOptimizer2..................................... 29
4-4. Checking the power saving level .............. 30
4-5. Enabling / Disabling Auto Power-OFF ...... 30
Chapter 5 Troubleshooting .............................. 31
5-1. No picture .....................................................31
5-2. Imaging problems (for both digital and
analog) .......................................................... 32
5-3. Imaging problems (for digital only) .......... 33
5-4. Imaging problems (for analog only) ......... 33
5-5. Other problems ........................................... 34
Chapter 6 Reference ........................................ 35
6-1. Attaching the Optional Arm ....................... 35
6-2. Connecting Multiple PCs ........................... 36
●
Toswitchamonginputsignals...................... 36
●
Tosetinputsignalselection...........................37
6-3. Making Use of USB (Universal Serial
Bus) ................................................................37
●
RequiredSystemEnvironment......................37
●
ConnectionProcedure(SetupofUSB
Function)........................................................ 38
6-4. Displaying Monitor Information ................ 38
6-5. Specications ............................................. 39
●
MainDefaultSettings.................................... 40
●
OutsideDimensions...................................... 40
●
Accessories....................................................41
6-6. Preset Timing ...............................................41
Chapter 7 Glossary .......................................... 42
Appendix .............................................................. 44
