EK QuantumX - Preparing the Monoblock; Removing the Backplate

- 10 -
Allen Key 2 mm
PREPARING THE MONOBLOCK
STEP 1
REMOVING THE BACKPLATE
First, unscrew (4) M3 x 18 DIN7991 Screws from the Backplate. Make
sure that the Terminal with O-ring stays in place. Save the removed
parts for later steps.
STEP 1
For this step, you will need:
M3 x 18 DIN7991 SCREW
