EK QuantumX - Monoblock

- 7 -
8
4
3
MONOBLOCK
Position EAN Description Quantity
1 106862 Coldplate (Ni) 1
2 106874 Top plate - plexi 1
3 106867 Front Cover (Black E.) 1
4 106869 Side Cover (PC White) 1
5 103305 Jet plate 1
6 106938 PCB -Power adapter 1
7 106945 PA housing bottom (Black E.) 1
8 106943 PA housing top (Black E.) 1
9 8205 Screw M4 x 10 DIN7991 28
10 8533 Standoff M4/M2.5 x 2.5 mm 5
11 9044 Screw M4 x 8 DIN7991 8
12 8541 Standoff M4/M2.5 x 6.60 mm 9
13 8204 Screw M3 x 20 DIN7991 2
14 106873 Wifi antena holder (Acetal) 2
15 8211 Screw M3 x 5 DIN7991 4
16 106986 OR - QuantumX PS5 1-2 1
17 5001 OR - 15 x 1.5 mm 1
18 100663 EK - Badge 1
7
16
13
10
1
2
12
15
14
6
17
11
15
9
14
18
5
