13 WARRANTY STATEMENT
The Elcometer 506 is supplied with a 12 month warranty against
manufacturing defects, excluding contamination and wear. The
warranty can be extended to two years within 60 days of purchase via
www.elcometer.com.
14 TECHNICAL SPECIFICATION
Dolly Diameter 14.2mm 20mm 50mm
Scale Range
(0 - 7600psi)
0 - 52 aMP 0 - 26 a
(0 - 3800psi)
MP 0 - 4.2 a
(0 - 610psi)
MP
Operating Range
(Certified)
4 - 50 aMP
(580 - 7260psi)
2 - 25 aMP
(290 - 3630psi) (45 - 580psi)
0.3 - 4 aMP
Scale Resolution
0.01 a
(1psi)
MP 0.01 a
(1psi)
MP 0.01 a
(1psi)
MP
Accuracy ±1% of full scale
Power Supply
2 x alkaline dry batteries
(rechargeable batteries can be used)
AA
Instrument
Weight
1.8kg (4lb) 1.8kg (4lb) 2.0kg (4.4lb)
Kit Weight n/a 4kg (8.8lb) 5.2kg (11.5lb)
Instrument
Length
290mm (11.5")
Actuator Height
(14.2mm skirt fitted)
85mm (3.4") 85mm (3.4")
(20mm skirt fitted)
110mm (4.3")
(50mm skirt fitted)
Note: The Elcometer 506 Adhesion Tester is a Type adhesion tester as defined byV
ASTM D4541.
Can be used in accordance with:
AS NZS ASTM ASTM BS DIN EN/ 1580.408.5, D4541, D7234, 1881-207, 1048,
12636, 13144, 1542, 16276-1, 4624, T30-606EN EN ISO ISO NF
