Elcometer 506 - Box Contents; Securing the Dolly

<
Elcometer 506 Adhesion Tester
<
Standard EpoxyAdhesive (2x15ml tubes)
<
Abrasive Pad
<
2 x BatteriesAA
<
Transit Case
<
Test Certificate
<
Calibration Certificate (if ordered)
<
User Guide
Additional items in 20mm Kit:
<
20mm Dollies (x10)
<
20mm Dolly Standard Skirt
<
20mm Dolly Cutter & Handle
Additional items in 50mm Kit:
<
50mm Dollies (x6)
<
50mm Dolly Standard Skirt
<
50mm Dolly Cutter with DrillArbor
2 BOX CONTENTS
www.elcometer.com
en-3
R
3 SECURING THE DOLLY
3.1 14.2mm 20mmUSING OR DOLLIES
1 Prepare the surface of the dolly and the coating where the dolly is
to be applied by roughening with the abrasive pad. Then
de-grease and clean both surfaces using a suitable solvent and
allow to dry.
2 Mix equal quantities of the two part Araldite
®
adhesive and apply
a thin, even layer to the prepared surface of the dolly.
4 Araldite adhesive is supplied by Elcometer however, other adhesives can
be used - see Section 12 ‘Adhesives’ on page en-12.
®
3 Press the dolly firmly onto the prepared test surface and apply
pressure to squeeze out excess adhesive which should then be
wiped clean.
4 Allow the adhesive to cure - see Section 12 ‘Adhesives’ on page
en-12.
4 If testing on vertical surfaces, you may wish to tape the dolly in place
during cure.
5 If required, score the coating around the dolly using the dolly
cutter provided.
