a Pressure Range Bar Graph
b On/Off & Enter Key
c Adhesion Reading
Digital Pressure Gauge
d Battery Life Indicator
e Units of Measurement ( or )MPA PSI
f Menu & Up Key
g Zero/Max Hold & Down Key
1 GAUGE OVERVIEW
6 Actuator Skirt
a
3 Digital Pressure Gauge
1 Lanyard Ring
2 Actuator
4 Crank Handle
5 Coarse Adjustment Screw
7 Quick Connect Coupling
www.elcometer.com
en-2
R
a
The Standard Actuator Skirt for 20mm dollies is illustrated above. Skirts for other dolly sizes and thin
substrates are also available - see Section 11.3 - “Dolly Skirts” on page en-11 for details.
a
c
d
e
b
f
g
6
3
4
1
5
6
2
1
7
7
