2.1 Technical specification
User GuideRG-1000e Remote Gateway
Multisite conventional network (IP Site Connect)
Single site trunking network (Capacity Plus)
Multisite trunking network (Linked Capacity Plus, Capacity MAX)
Power supply
Supply voltage
11–15.0 VDC, power can be applied via Power socket and\or radio
Radio1 socket and\or radio Radio2 socket
Power consumption
200 mA or less
Design
Dimensions
180x144x30 mm
Ethernet connector
RJ45 8P8C (8 pins)
Radio connector
3M 10126-*** jack (26 pins)
Power connector
Phoenix Con PTSM 0.5-3 (3 pins)
Audio connector
Phoenix Con PTSM 0.5-2 (2 pins)
Terminal connector
USB mini-B jack (4 pins)
Operating conditions
Operating temperature range
–4° to 140°F (–20° to +60°C)
Relative humidity
Up to 85% at 86°F (30°C)
Operating hours
24x7
Control terminal
Interface port
USB 1.0 (12 MBps), Device port
Software
RG-1000e Customer Programming Software (RG-1000e CPS)
2.2 Delivery set
The RG-1000e GATEWAY delivery set includes the following components:
· RG-1000e GATEWAY
—1 pcs.,
· interface cable*
—1 pcs.,
· FTP5E cable, 6.56 feet (2 m)
—1 pcs.,
· the following clamping elements of RG-1000e GATEWAY:
o bracket
—2 pcs.,
o M3x6 screw
—4 pcs.,
o M5x10 screw
—2 pcs.,
o 5x20 self-tapping screw
—4 pcs.,
