2.1 Technical specification
User GuideRG-1000e Remote Gateway
2.1 Technical specification
Technical parameters of the RG-1000e GATEWAY are listed in table 1 below.
Table 1 RG-1000e GATEWAY technical parameters
Network interface parameters
Connector
RJ45
Standard
10BASE-T (IEEE 802.3) / 100BASE-TX (IEEE 802.3u)
Supported TCP/IP protocols
UDP, ICMP, IPv4, ARP
Auto tuning of auto switching
Transmission rate—10/100 Mbps
Operation mode—duplex/half-duplex
Auto detection of the cable type—Auto-MDI/MDI-X
Radio interface parameters
Number of ports for radio connections
Two ports, Port 1 and Port 2 may be used simultaneously, independently
from each other
Voice channel
768 kbps (48 kHz x 16 bits) PCM, duplex
Frequency band of voice channel
20–3600 Hz
IP voice channel coding
64 kbps (G711 A-Law/Mu-Law)
Transport protocol of control channel
UDP and TCP
Required bandwidth for control
channel
From 15 kbps
Transport protocol of voice channel
UDP and RTP
Required bandwidth for voice IP
channel
~128 kbps
Time delay\latency (SmartPTT
Radioserver <-> RG-1000e), ms
Up to 1250 ms one-way (2500 ms round-trip)
Support of radio operation modes
MOTOTRBO radio models
EMEA region DM46**e, DM44**e, DM46**, DM44**, DM2600; APAC
region XiR M8600i, XiR M8600, XiR M6660; NA region XPR 5***e,
XPR 5***, XPR 2500; LA region DGM8***e, DGM 5***e, DGM 8***, DGM
5***, DEM500
Radio operation modes
Digital MOTOTRBO
Analog MOTOTRBO
MOTOTRBO network topologies
Talkaround mode
Single repeater
