ELECRAFT KRX3 - E850249 I.F. Crystal Filter Bag (or Box)

10
E850249 I.F. Crystal Filter Bag (or Box)
NOTE: If the optional 8-pole 2.8K filter is purchased instead (see next item) this filter is not supplied.
ILLUSTRATION DESCRIPTION QTY
ELECRAFT
PART NO.
KFL3A-2.7K Filter
Note: This filter is not supplied if you
purchased the optional 8-pole 2.8 kHz
filter with your K3 kit.
1 E850249
or
Screw, 4-40, either 1/4” (6.4 mm) Zinc,
Pan Head or 3/16” (4.8 mm) Black Pan
Head screw.
1
E700005 or
E700015
or
Lock Washer, #4, Interior Tooth or Split
Ring
1
E700010 or
E700004
E850249 I.F. Crystal Filter Bag (or Box)
OPTION: Not supplied unless ordered. Otherwise the standard 5-pole filter (above) is supplied.
ILLUSTRATION DESCRIPTION QTY
ELECRAFT
PART NO.
KFL3A-2.8K Filter (optional, see above) 1 E850249
or
Screw, 4-40, either 1/4” (6.4 mm) Zinc,
Pan Head or 3/16” (4.8 mm), Black Pan
Head screw.
1
E700005 or
E700015
or
Lock Washer, #4, Interior Tooth or Split
Ring
1
E700010 or
E700004
