Parts Included
The following parts should be included in your kit. Check to ensure you have them all. If any parts are damaged
or missing, contact Elecraft for replacements (see page 4).
Circuit Boards and Enclosure
Note: Some pins on the male connectors may have been removed and some holes in the female connectors may
have been plugged. This is intentional to help you align the connectors properly during assembly.
ILLUSTRATION DESCRIPTION QTY.
ELECRAFT
PART NO.
Auxiliary DSP Printed Circuit Board
Assembly
ESD Sensitive. Follow ESD safe handling
procedures. Keep in ESD-safe bag until installed.
1 E850234
KSYN3A Synthesizer
Printed Circuit Board Assembly
ESD Sensitive. Follow ESD safe handling
procedures. Keep in ESD-safe bag until installed.
One pin on the multi-pin connector has been
removed intentionally.
1 E850638
KRX3A Main Printed Circuit Board
Assembly
ESD Sensitive. Follow ESD safe handling
procedures. Keep in ESD-safe bag until installed.
1 E850276
K3 Mixer Board
ESD Sensitive.
1 E850257
KNB3 Noise Blanker Board
ESD Sensitive.
1 E850280
