ASSEMBLY
HOW TO ASSEMBLE YOUR ELECTRABRAKE
The EB2000, EB2500, EB3200
Note: The machine is supplied upside down for assembly purposes.
1. Remove all parts from the crate with the exception of ELECTRABRAKE magnet body
assembly.
2. Find the 6mm Allen Key and the screws supplied.
3. Lift the magnet body up from the crate. Place a plank between the body and the crate.
4. Attach the columns to the magnet body by using four M8 x 16 cap-head screws per column.
Open-out the bending beam to gain access to insert the screws.
5. NB Check that the right and left columns are in the correct position with the foot mounting
holes facing to the outside.
6. Attach the feet to respective columns with the adjusting screws pointing backwards using
four M10 x 16 button-head screws per foot.
7. Place the machine the right way up. Assistance is required on the large units.
8. Use four M8 x 16 cap-head screws to attach shelf to the columns. Place the rubber mat in
the shelf.
9. Use three M8 x 12 cap-head screws to attach the tray to the magnet body. Place the rubber
mat in the tray.
10. Use two M8 x 12 screws per backstop to attach the four backstop bars to the back of the
magnet body.
11. Use one M8 x 20 cap-head screw with lock nut per lifter handle to attach lifter handles to the
back of the shaft located at the outside of the columns.
12. Open the bending beam to gain access to the back of the bending beam so that you can
attach the handles
13. Use two M8 x 20 cap-head screws per handle to attach the handles to the bending beam.
14. The handle with the angle scale is attached to the right of the bending beam. Attach the
other handle on the left hand side.
15. Slide the angle indicator unit onto the right handle. Attach the 2 arms to the indicator spindle.
To ensure correct operation securely fasten the screws to the switching mechanism.
16. Use the two M12 x 60 masonry bolts supplied to secure the Electrabrake machine to the
floor. Adjust the head levelling screws in the rear of each foot until the machine is stable and
level.
17. Use solvent i.e. turpentine or methylated spirits to remove the clear protective coating from
the top of the unit and the clamp bar.
18. Place the clamp bar on the magnet body. To engage the heads of the lifter pins push lifter
handle back and then pull the handle forward.
19. To obtain excellent results follow the operating instructions.
Instruction Manual for EB2500 (S5321)
