ASSEMBLY
HOW TO ASSEMBLE YOUR ELECTRABRAKE
The EB625, EB1000
Note: The machine is supplied upside down for assembly purposes.
1. Remove all parts from the crate with the exception of ELECTRABRAKE magnet body
assembly.
2. Use the 6mm Allen Key and the screws supplied.
3. Place packing between the body and the crate.
4. Attach the feet to the column using the eight M10 x 16 button-head screws provided. Note
that the seam on the column is at the back and the two feet with the yellow and black safety
tape are the front feet.
5. Fasten the foot plate under the front feet using the M10 x 16 cap-head screws with washers.
Alignment is easier if the foot mounting is not tightened until the foot plate is fitted. The rear
feet cap head screws can be adjusted to level the machine.
6. Place the stand on its feet in a safe area so that the magnet body can be fastened to the
stand.
7. Place the magnet body on the stand securing it with two M8 x 16 cap head screws. This
would be best of you used a lifting device or got some assistance. Ensure that the magnet
wires are guided down the column as the magnet body is lowered onto the stand.
8. Remove the rear access cover to gain access to the electrical unit. By removing the four pan
head screws. Connect the adjoining matching plug leads from the magnetic coil and PC
board. Refit the rear access cover.
9. On the EB625 the tray is in two halves. First join the two halves of the tray using the two M6
pan head screws and nuts. Now using two M8 x 12 cap head screws attach the tray to the
back of the magnet body. Place the rubber mat in the tray. Attach the back stop slides to the
side of the tray.
10. On the EB1000 use four M8 x 12 cap head screws to attach the two back stop bars to the
back of the magnet body
11. On the EB1000 use three M8 x 12 cap head screws to attach the tray to the back of the
magnet body between the two back stop bars. Place the rubber mat in the tray.
12. Open the bending beam to gain access to the back of the bending beam so that you can
attach the handle.
13. Slide the handle through the angle indicating ring. Now using two M8 x 16 cap-head screws
to attach the handle to the bending beam.
14. Use solvent i.e. turpentine or methylated spirits to remove the clear protective coating from
the top of the unit and the clamp bar.
15. Place the clamp bar on the magnet body.
16. To obtain excellent results follow the operating instructions.
