C O N T E N T S
Page number
Introduction 3
Risk assessment 4 ā 6
Pace maker warning 7
Assembling the EB0625, EB1000 8
Assembling the EB1250 9
Assembling the EB2000, EB2500, EB3200 10
Operating procedures for the EB2000, EB2500 and EB3200 11
General cautionary important warnings 11
Safety procedures: 11
Standard bending 11
How to use the backstops 12
How to fold a lip 12
How to make a rolled edge 13
How to form a test piece 14
Basic boxes 15
Lipped boxes 15
Boxes with individual ends 16
Flanged boxes with plain corners 16
Flanged box with corner tabs 17
How to use a slotted clamp bar 18
Forming trays 18
How to check the accuracy of your machine 19
How to check using th
e machine. 19
Maintenance 20
Adjusters 20
Hinge lubrication 20
Working surfaces 20
Trouble shooting 20
Full clamping not operating 21
Clamp bar not being released 21
Problems with the bending of heavy gauge sheet metal. 22
EB 625 and EB1000 panel 23
EB 2000 EB3200 Wire panel 24
EB-0625 EB1250 Circuit diagram 25
EB 2000, EB2500 and EB3200 circuit diagram 26
Specification sheet 27
Dimensional specifications EB625 28
Dimensional specifications EB1000 28
Dimensional specifications EB1250 29
Dimensional specifications EB2000 30
Dimensional specifications EB2500 30
Dimensional specifications EB3200 31
Warranty 32
Warranty registration 33
ANEXURE 1
Basic Safety Precautions and Procedures: 34-35
FRAME ASSEMBLY AND PARTS LIST EB2000, EB2500, EB3200 36-37
Packing Lists for EB 625 ā EB 3200 38-43
Instruction Manual for EB2500 (S5321)
