PACKING LIST FOR EB3200 ELECTRABRAKE BENDING MACHINE
MACHINE SERIAL NUMBER_______________________________
PART NUMBERS
DESCRIPTION
QTY
CHECKED
EB-119
SAFETY CABLE ASSY
2
EB3200-TEST PIECE
3200 BENDER – TEST PIECE
1
EB-024
BASIC ASSEMBLY 3200
1
EB-001
STAND ASSY
1
EB-002
INDICATOR ASSEMBLY H.D.
1
EB-025
BENDING BEAM EXTENSION
1
EB-028
LIFTER MECHANISM – 3200
1
EB-010
HANDLE REINFORCED
1
EB-011
HANDLE REINFORCED (GROOVED)
1
EB-012
STOP COLLAR
5
EB-015
BACK STOP BAR – ASSY
4
EB-016
LARGE TRAY
1
EB-017
RUBBER MAT
1
EB-006
COVER END PLATE
2
EB-007
COLUMN BLOCK
2
EB-008
COVER CENTRAL
1
EB-009
ACCESS PANEL
1
EB-023-01
3200 COVER PLATE R/H
1
EB-023-02
3200 COVER L/H
1
EB-107 (DECALS)
EB3200 3240X95 BLK/RD C
1
EB-110-FRONT
STICKER FOR ELECTRABRAKE
1
EB-110/B
FUSE 3 VARIANT (20A) WA
1
EB-111
START LABEL
2
EB-111-BACK
STICKER FOR ELECTRABRAKE
1
EB-112-LEFT
STICKER FOR ELECTRABRAKE
1
EB-113-RIGHT
STICKER FOR ELECTRABRAKE
1
EB-225-RULER
EB1250 ALUMINIUM RULER
1
EB-026
CLAMPBAR FULL LENGTH
1
EB-019
CLAMPBAR 600 LONG
1
EB-020
CLAMPBARS (SHORT SET)
1
EB-021
CLAMPBAR 1160
1
EB-083
FOOT SWITCH ASSY
1
EB-118
SUPPORT LEG ASSEMBLY
2
EB-3200-CRATE
3365X295X250 WOODEN CRATE
1
EB-ELEC-3.2/PCB
3.2MT ELECTRICAL UNIT
1
EB-HAR 1250/S
1250 HARNESS – SHORT
1
EB-HARNESS 3.2
3.2 ELECTRICAL HARNESS
1
ELEC474
SOCKET HOUSING 3 PIN 29
1
ELEC476
CRIMP TERMINAL PINS 29
1
PAN-M10X16
10X16 POZI S/T PAN HEAD
6
PAN-M6X10
M6X10 POZI PAN HEAD SCR
24
R/BOLT-M12X60
M12X60 RAWL BOLT
2
A/KEY-M6
M6 ALLEN KEY LONG SERIES
1
CAP-M8X12
M8X12 SOCKET HEAD CAP S
1
CAP-M8X16
M8X16 SOCKET HEAD CAP S
15
CAP-M8X25 HT
M8X25 CAP SCREWS HT
15
