6. Energy Saving Functions
6.3. End User Behaviour Indicator
The end user behaviour indicator is a traffic light system to warn of high temperature
(high consumption).
The display has a backlight that changes colour as the temperature set is increased or
lowered.
The indicator colour helps to educate the end user when they set manually the Comfort
temperature by visual information regarding the risk of energy consumption to maximise
energy savings.
Colour of screen:
GREEN from 7 to 19
o
C , when it is considered that power consumption and performance
are suitable.
YELLOW/ORANGE from 19 degrees to 24 oC, as the screen colour changes towards red,
this indicates an increased risk of higher power consumption.
RED 24
o
C and above indicates the risk of excessive consumption of electricity.
IMPORTANT NOTE: This colour is only indicative only and is assumed that the correct
size radiator has been chosen for the room size. If the radiator feels hot all the time and
the resistor symbol is displayed often, the radiator is too small for the area it is designed
to heat. The screen could still be GREEN but the radiator is working too hard.
Resistor symbol
