FUNCTIONS
POWER
Press “POWER” to turn the unit On or Off
MODE
Press to change between the 4 different modes. The display will show the symbol for the mode
currently selected.
COOLING
Cooling mode defaults to 22°C and will cool the air while sending warm air outside.
The desired temperature can be adjusted using the increase and decrease button
between 16°C and 30°C. The fan speed can also be adjusted using the speed button.
DRY
Dry mode will extract moisture from the air, which will be drained outside using the
installed drain pipe. The fan speed cannot be adjusted in dry mode.
FAN
In fan mode the appliance will recirculate the air within the room, and will not cool
or dehumidify. The fan speed can be adjusted using the Speed button.
HEATING
Heating mode defaults to 24°C and will heat the air while sending cool air outside.
The desired temperature can be adjusted using the increase and decrease button
between 16°C and 30°C. The fan speed can also be adjusted using the speed button.
SLEEP
Sleep mode can only be activated from the control panel by pressing the timer and
up buttons at the same time. It will only operate in cooling or heating modes. In
cooling mode, the fan speed will change to low, and the desired room temperature
will increase by 1°C after 1 hour, and a second 1°C after 2 hours, reducing the
amount of time the compressor operates. In heating mode it works exactly the
same, but the desired temperature is decreased.
FAN SPEED
Press to change the fan speed between Low, Medium and High. The fan speed
cannot be adjusted in Dry or Sleep modes.
TIMER
The air conditioner contains a 24 hour timer, which can be used to either set a delayed start, or a
set period of operation. The timers cannot be combined, although the app can be used to
program periods of operation.
SHUTDOWN TIMER: While the unit is running press the timer button, the display will flash “0” 5
times. After the 5
th
flash, use the up and down buttons to adjust the duration in 1 hout
increments between 1 to 24 hours. When the timer has elapsed, the unit will shutdown
automatically.
DELAYED START TIMER: With the unit in standby, press the timer button, the display will flash
“0” 5 times. After the 5
th
flash, use the up and down buttons to adjust the duration in 1 hout
increments between 1 and 24 hours. After the timer has elapsed, the unit will start up in the
same mode with the same settings as when it was turned off.
INCREASE AND
DECREASE
Used within cooling and heating modes to adjust the desired room temperature.
Also used while setting the timer to adjust the duration.
SWING MODE
After machine turns on, press the “SWING” button, louver will swing continuously up and down;
by pressing the button again the movement will stop and the louver remain in that position. Swing
mode can only be adjusted from the remote, and will initially be turned on by default.
COMPRESSOR
PROTECTION
There is a 3 minutes delay on power on. In order to protect the life of the compressor and
electronic components please do not switch on the unit for at least 5 minutes after you turned the
unit off.
