- 17 -
NOTE INTERVAL CHART FOR -1 AND +1 OCTAVE
SETTING -1 Octave Interval /
Example Note
+1 Octave Interval /
Example Note
0 Unison / C Unison / C
10
20
30
40
50 Perfect 4th / G Perfect 4th / F
60 Tritone / Gb
70 Perfect 5th / F Perfect 5th / G
80
90
100
110
120 Octave / C Octave / C
Note: The above chart does not pertain to the -2, +5th, or +2 voices
as they will produce other intervals at the above settings.
Toe Trans: Set the interval for the toe position, with same range as the heel.
Reverse: Off/On
Calibration: Set>
No-Pedal Value: 0-127
Reverse: Off/On
Calibration: Set>
No-Pedal Value: 0-127
Warp (WRP) Warp mode engages whammy style pitch bend on all voices
except DRY. FOCUS must be enabled to Warp—or bend—the +1 and +2
Octaves. The -2, -1, and +5th voices are always available for Warp sweep.
Heel Trans: Set the interval for the heel position, ranging from 0 to 120,
where each decade is a note on the chromatic scale, the standard notes
on a piano keyboard. See the note interval chart below. You may also
further adjust cents between 0 and 9.
