Interfaces
CAN-Bus, 10 ... 500 kbit/s, RJ-45 (PC Control)
RS-232, 19.2 kbit/s, 9-pol. SUB-D (Multi Media Control)
Control Port / GPIO
6-pol. Phoenix
2 Control Inputs
Inactive / OFF +5.0V (> 2.4V) or open (internal pull-up)
Active / ON
0V (< 0.8V)
2 Control Outputs
Inactive / OFF High (Open Collector)
Active / ON
Low (< 0.5V / I = 0.7A)
Input Voltage
+32.0V max.
Switching Current 1.0A max.
Reference Outputs +5.0V / 100mA and GND
Power Requirements
240V, 230V, 120V, 100V / 50Hz ... 60Hz,factory con gured
Power Consumption

max. output voltage at rated load
690W
870W
Protection
Audio limiters, High temperature, DC, HF, Back-EMF,
Peak current limiters, Inrush current limiters, Turn-on delay
Cooling
Front-to-rear, 3-stage-fans
Dimensions
(W x H x D), mm
483 x 132.5 x 426
Weight
22kg
24kg
Optional Input Transformer
Optional Output Transformer
(Monitor)
Rear-rackmount 15,5“
Rear-rackmount 18“
NRS 90208 (121 641)
NRS 90227 (112 679)
NRS 90235 (112 733)
NRS 90223 (112 701)
SPECIFICATIONS / TECHNISCHE DATEN
