34 electrolux
Replacing the Oven Light
Bulb
If the oven bulb needs replacing, the new
bulb must have the following specifications:
- Electric power: 15 W/25 W,
- Voltage: 230 v (50 Hz),
- Resistant to temperatures of 300 °C,
- Connection type: E14.
These replacement bulbs can be purchased
from your dealer.
To replace the oven light bulb (Fig.
43):
1. Ensure the oven is disconnected
from the electrical supply.
2. Turn the glass cover anti-clockwise.
3. Remove the faulty bulb and replace with
the new one.
4. Refit the glass cover.
5. Turn the power on again.
Fig. 43
)
Oven Shelf Support Rails
The shelf support rails on the left and right
hand sides of the oven can be removed for
cleaning the side walls.
Removing the shelf support rails
First pull the front of the rail away from the
oven wall and then unhitch at the back (40,
41).
Fitting the shelf support rails
To install, first reattach the rails at the back,
then put them into position at the front and
press them into place (42).
To clean the shelf support rails, soak in warm
soapy water and remove stubborn marks
with a well wetted soap impregnated pad.
Rinse well and dry with a soft cloth.
When cleaning the shelf
supports, take care not to
remove the lubricating grease
behind the telescopic runners.
This is meant to ensure their
good operation.
40
41
42
