2-3
Section 2 Installation Instructions
Shave
Raised
Edge To
Clear
Space for
31½" (80
cm) Wide
Cooktop
Rim.
Grounded Junction Box or Wall Outlet Should Be
Located 8" to 17" (20,3 - 43,2 cm) From Right Cabinet
and 2" to 4" (5,1-10,2 cm) From Floor
24" Min.
(61 cm) Min.
30" Min.
(76,2 cm) Min.
13"
(33 cm)
Locate Cabinet Doors 1" (2,5 cm) Min.
From Cutout Opening
Approx. 1 7/8"
(4,8 cm)
18" Min.
(45,7 cm) Min.
30" Min. (See Page
2-10, Note 3)
(76,2 cm) Min. (See
Page 2-10, Note 3)
1½" Max.
(3,8 cm Max.)
1 1/8"
(2,86 cm)
FRONT OF
CABINET
F
Ref.
22 7/8"(58,1 cm) min.
23 1/4"(59,05 cm) max.
(see Note 4)
IMPORTANT: Cabinet and countertop
width should match the cutout width.
***IMPORTANT: To avoid cooktop breakage for cutout width (E dimension) of more than 30 1/16" (76,4 cm),
make sure the appliance is centered in the counter opening while pushing into it. Raise leveling legs and the
rear adjustable wheels at a higher position than the cabinet height (see page 5), insert the appliance in the
counter and then level. Make sure the unit is supported by the leveling legs at the front and the wheels at the
back and NOT by the cooktop itself.
Cabinet Dimensions
E
E
E. CUTOUT WIDTH
(Countertop and cabinet)***
F. CUTOUT DEPTH
G. HEIGHT
OF COUNTERTOP
30±1/16"
(76,2±0,16 cm)
21 3/4" (55,2 cm) Min.
22 1/8" (56,2 cm) Max
24" (61 cm) Min. with backguard
35 7/8" (91,1 cm) Min.
36 5/8" (93 cm) Max.
Countertop hatched
surfaces should be at
& leveled.
½" Min.
(1,3 cm) Min.
½" Min.
(1,3 cm) Min.
3/8" Min.
(0,95 cm) Min.
To Next Page
