SOI 04.05 FV 24/57 599 36 62-62
5. OPERATING THE HOB (extract from Instruction Booklet)
Before using the appliance, remove all
packaging material, including advertising
labels and protective film, if any.
5.1 TOUCH CONTROL KEYS
The hob is operated using special "touch control" sensor
keys.
To operate the hob, simply touch the appropriate sensor
with a fingertip.
Do not touch more than one sensor at a time when
operating the hob.
The symbols listed below indicate the functions of the
various touch keys.
Main ON/OFF (touch control)
Light burner (touch control)
Flame level indicator LEDs
Increase flame setting
Reduce flame setting
Residual heat warning LED
BURNER CONTROL AREA
Fig. 19
5.2 LIGHTING THE BURNER
1. Touch the main ON/OFF key for three seconds to
switch the hob on.
The red LED above the touch control will light, and the
buzzer will sound.
The hob is now ready for use.
Fig. 20
