Electrolux Smart Variomix Service Manual

Fet stil = Ändring
Bold print = Change
Fettdruck = Änderung
45
Standard Line/ Medium Line, Eluppvärmd Utgåva Månad År
Standard Line/ Medium Line, Electrical heated Edition Month Year
Standard Line/ Medium Line, El. beheiz Ausgabe Monat Jahr
5 10 2010
Antal Art.nr Anm.
Pos. Quantity Art. no Benämning Description Bezeichnung Notes
Anzahl Art. Nr Anm.
Illustration 21658
1). Standard Line
2). Medium Line
[ 50 L
[ 100 L
[ 150 L
[ 200 L
[ 300 L
1 2 2 2 2 2 482 68 08-01 Vred Knob Drehknopf 1).
2 2 2 2 2 548 83 72-00 Vred Knob Drehknopf 2).
2 2 2 2 2 2 491 42 24-00 Tätningsbricka Sealing washer Dichtungsscheibe
3 1 1 1 1 1 428 12 97-00 Panel Panel Verkleidung 1).
1 1 1 1 1 428 16 71-00 Panel Panel Verkleidung 2).
4 1 1 1 1 1 763 10 01-02 Lampa Lamp Lampe
5 1 1 1 1 1 ST0 86 26-00 Vridströmställare Switch Schalter
6 1 1 1 1 1 767 11 01-00 Tryckknapp Push-button Drucktaste
7 1 1 1 1 1 464 28 96-06 Plint Block Klemme
8 1 1 1 1 1 491 46 05-01 Regulator Regulator Regulator
9 1 1 1 1 1 428 13 63-00 Vridomkopplare Switch Umschalter
10 1 1 1 1 1 428 46 76-00 Täckbricka Cover palte Abdeckscheibe
11 1 1 1 1 1 428 46 77-00 Packning Gasket Dichtung
12 1 1 1 1 1 482 46 78-00 Bricka Washer Scheibe
13 1 1 1 1 1 428 09 34-00 Slang Hose Schlauch
14 1 1 - - - 428 15 75-00 Tak Top Dach 1).
1 1 - - - 428 16 31-00 Tak Top Dach 2).
- - 1 1 1 428 15 74-00 Tak Top Dach 1).
- - 1 1 1 428 16 32-00 Tak Top Dach 2).
15 1 1 1 1 1 741 21 13-20 Muff Sleeve Stutzen
16 2 2 2 2 2 552 21 40-21 Slangnippel Hose nipple Schlauchnippel
17 1 1 1 1 1 428 07 58-01 Slang Hose Schlauch L= 500mm
18 2 2 2 2 2 428 14 71-01 Backventil Non return valve Rückslagventil
19 1 1 1 1 1 482 30 93-00 Tappventil Valve Ventil
20 2 2 2 2 2 741 31 13-22 Nippel Nipple Nippel
21 1 1 1 1 1 742 51 13-20 T-rör Pipe Rohr
22 1 1 1 1 1 743 46 45-20 V-koppling Water coupling Wasserkupplung
23 1 1 1 1 1 743 46 55-20 V-koppling Water coupling Wasserkupplung
24 2 2 2 2 2 743 46 35-30 V-koppling Water coupling Wasserkupplung
25 1 1 1 1 1 428 09 32-00 Blandare Tap Wasserhahn
26 1 1 1 1 1 428 09 33-00 Handdusch Sprayunit Handdusche
27 1 1 1 1 1 428 13 66-00 Komponent plåt Component panel Komponentenbrett
