1). Standard Line, Medium Line
2). Variomix, Top Line
3). Promix
4). Comfort
5). Till 2003.10 To 2003.10 Zu 2003.10
6). Fr.o.m. 2003.10 From 2003.10 Ab 2003.10
7). Fr.o.m. 2009.04 From 2009.04 Ab 2009.04
Fet stil = Ändring
Bold print = Change
Fettdruck = Änderung
47
Ellåda,Ånguppvärmd 50-100L Utgåva Månad År
Electric box, Steam heated 50-100L Edition Month Year
Eletrischebüsche,Dampfbeheiz 50-100L Ausgabe Monat Jahr
6 03 2011
Antal Art.nr Anm.
Pos. Quantity Art. no Benämning Description Bezeichnung Notes
Anzahl Art. Nr Anm.
Illustration 21662
[ 50 L
[ 100 L
1 1 1 428 06 46-00 Ellåda Electric box Electrischebüsche
2 1 1 475 93 46-17 Monteringsskena Mounting slide Montageschiene
3 1 1 552 22 21-03 Säkringsautomat Automatic fuse Automatsicherung 400V 2). 3).
2 2 552 22 21-03 Säkringsautomat Automatic fuse Automatsicherung 230V 2). 3).
4 2 - 552 22 21-16 Säkringsautomat Automatic fuse Automatsicherung 230V, 2). 16A
- 1 552 22 21-16 Säkringsautomat Automatic fuse Automatsicherung 400V, 2). 16A
- 1 552 22 23-25 Säkringsautomat Automatic fuse Automatsicherung 230V, 3). 25A
- 2 552 22 21-20 Säkringsautomat Automatic fuse Automatsicherung 230V, 2). 20A
- 1 552 22 23-20 Säkringsautomat Automatic fuse Automatsicherung 400V, 3). 20A
- 1 552 22 21-20 Säkringsautomat Automatic fuse Automatsicherung 400V, 2). 20A
5 2 2 767 51 02-09 Kontaktor Contactor Kontaktor 2). 3). 4). 5).
2 2 ST0 27 90-10 Kontaktor Contactor Kontaktor 2). 3). 4). 6).
6 1 1 767 51 12-09 Kontaktor Contactor Kontaktor 2). 3). 4). 5).
1 1 ST0 27 90-00 Kontaktor Contactor Kontaktor 2). 3). 4). 6).
7 1 1 552 22 15-00 Nätfilter Filter Filter
8 1 1 767 51 02-92 Hjälpkontaktblock Support contact plate Hilfskontaktblech 2). 3).
9 1 1 552 22 20-00 Tidrelä Time relay Zeitrelais 2). 3).
10 4 4 552 22 50-02 Kopplingsplint Grå 4 Block terminal Grey 4 Klemmenbrett Grau 4
11 1 1 552 22 54-00 Ändplatta End plate
12 5 5 552 22 51-02 Kopplingsplint Blå 4 Block terminal Blue 4 Klemmenbrett Blau 4
13 1 1 552 22 52-05 Kopplingsplint G/G 16 Block terminal Y/G 16 Klemmenbrett G/G 16
1 1 552 22 52-04 Kopplingsplint G/G 10 Block terminal Y/G 10 Klemmenbrett G/G 10 6).
14 3 3 552 22 51-02 Kopplingsplint Blå 4 Block terminal Blue 4 Klemmenbrett Blau 4
15 1 1 428 04 10-00 Allpolig enkelbrytare Switch Schalter
16 4 4 552 22 52-02 Kopplingsplint G/G 4 Block terminal Y/G 4 Klemmenbrett G/G 4
17 1 1 552 22 52-05 Kopplingsplint G/G 16 Block terminal Y/G 16 Klemmenbrett G/G 16
18 1 1 475 93 46-09 Monteringsskena Mounting slide Montageschiene
19 2 2 762 11 13-55 Mutter Nut Mutter PR 37
20 2 2 762 21 13-06 Hylsa Sleeve Hülse PR 37
21 3 3 ST0 28 64-03 Mutter Nut Mutter M20x1,5
22 1 1 762 11 08-55 Mutter Nut Mutter PR 15,2
23 3 3 ST0 36 56-02 Kabelförskruvning Pipe nipple and nut Verschraubung M20x1,5
1 1 ST0 36 56-03 Kabelförskruvning Pipe nipple and nut Verschraubung M25x1,5 7).
24 1 1 762 21 08-06 Hylsa Sleeve Hülse PR 15,2
